CED-MS is a fully automatic cotton stuffing machine used to automatically and accurately insert cotton strips into various types of bottles. The device has a simple and reasonable structure, and is easy to operate. Its production speed can be adjusted according to bottle specifications and characteristics, suitable for glass and plastic bottles in industries such as food, medicine, and cosmetics. In addition, the equipment has multiple detection and alarm control functions such as bottle free operation, fault self inspection, and cotton strip replacement warning, which can ensure the continuity and accuracy of production.
The product is manually placed on one side of the roller, and the equipment automatically operates to feed, pull cotton, insert cotton tube, turn to the bottle mouth, and insert cotton into the bottle. The equipment will automatically position and fix the bottles. When the bottle positioning time reaches the parameters set by PLC programming, the pneumatic system will automatically replace the bottles, achieving fully automated operation, and each bottle can be filled multiple times.
| Model | CED-MS |
|---|---|
| Filling speed | 10~40 bottles/minute |
| Bottle outer diameter | Φ20~80mm |
| Bottle height | 35~200mm |
| Total power of equipment | 700W |
| Dimensions | 1360*800*1550mm |
| Weight | 280kg |
| Conveying direction | Left→Right |
Reasonable structural design: The equipment structure is simple, easy to understand and operate, and convenient for daily maintenance and repair.
Easy to operate: The user interface is user-friendly, and operators can proficiently use it after simple training.
Strong adaptability: The production speed can be flexibly adjusted according to the bottle specifications, suitable for various sizes of glass and plastic bottles.
Complete detection function: equipped with multiple detection and alarm control functions such as bottle free operation, fault self inspection, cotton strip replacement warning, etc., it can timely detect and handle abnormal situations, ensuring stable production.
Compliant with standards: Some materials comply with GMP (Good Manufacturing Practice) requirements and are suitable for industries with high hygiene standards.
Pharmaceutical industry: used for filling cotton inside medicine bottles to prevent damage caused by collisions during transportation, while maintaining a dry environment inside the bottles.
Food industry: Cotton is stuffed into some food packaging bottles (such as candy bottles, snack bottles, etc.) to provide cushioning and moisture resistance.
Cosmetics industry: For cosmetics bottles, such as essence liquid bottles, face cream bottles, etc., use cotton filling for protection and isolation.
