Material supply: Powder materials enter the screw conveyor system from the silo;
Quantitative measurement: By driving the screw to rotate with a servo motor or stepper motor, the required weight of powder is accurately measured according to preset parameters;
Automatic filling: The measured powder is filled into containers (such as bottles, cans, bags);
Auxiliary functions: optional vibration device, dust cover, dust removal system, etc., to ensure a clean and smooth filling process.
| Model | CN-HZFB |
|---|---|
| Max capacity | 10-30 bottle/min |
| Dia. of bottle | φ20-150mm |
| Height of bottle | 60-300mm |
| Power | 0.8KW |
| Voltage | AC220V,50/60HZ |
| Dimensions | 900x900x2000mm |
| Weight | 280kg |
High precision measurement: using high-quality stainless steel screws, with a measurement error of less than ± 1%;
Easy to operate: PLC control system, touch screen human-machine interface, simple and intuitive parameter settings;
Strong compatibility: compatible with various specifications of containers and different types of powders;
Easy to clean: modular design, quick disassembly and assembly, in compliance with GMP standards;
Save labor: semi-automatic operation, one person can simultaneously complete the filling of multiple containers;
Strong scalability: Automatic feeding machines, automatic sealing machines, and other equipment can be added according to production needs to achieve production line linkage.
Food industry: milk powder, coffee powder, protein powder, flour, seasoning, etc;
Pharmaceutical industry: pharmaceutical powders, pharmaceutical raw materials, traditional Chinese medicine powders, etc;
Chemical industry: additives, pigments, chemical raw materials, pesticide powders, etc;
Cosmetics industry: pearl powder, whitening powder, skincare powder, etc;
Other industries: Daily chemical product powders, feed powders, etc.
If you are looking for an efficient and reliable Auger Powder Filling Machine, please feel free to contact us anytime!
